NETZSCH 6617 brake pad drawing: unconfirmed × unconfirmed mm, 17 mm thick
NETZSCH 6617 brake pads in NH65, pixel art
The lab boy dressed for NH65
The NH65 pad box

6617

149.1 x 72.9 x 17 mm; Wilwood Aero4 Radial Mount; Wilwood Aero4-DS Radial Mount; Wilwood Aero6 Radial Mount

Made to the Wilwood 6617 pad shape. Compare the outline and thickness with your old pads.

Pad shape
Wilwood 6617
Size
149.1 × 72.9 mm
Thickness
17 mm
Use
Race calipers
Formula

For carbon-ceramic discs

NH65: High Performance Racetrack Series, rated to 900°C. About NH65

Price on requestRetail prices are being finalised
Request price

  • Price and stockLoaded from the store for the selected formula; ask us if no price is shown.
  • DeliveryOptions and cost are shown at checkout for your address.
  • Before fittingCompare the drawing, size and thickness with the pads you remove.

Shipping · Returns · Warranty

Not sure this is your shape? Use the part finder or ask support.

Fits

Race calipers

BrandCaliperNotes
WilwoodAero4 Radial Mount6617; 17 mm
WilwoodAero4-DS Radial Mount6617; 17 mm
WilwoodAero6 Radial Mount6617; 17 mm
WilwoodAero6-DS Radial Mount6617; 17 mm
WilwoodAeroDM Lug Mount6617; 17 mm
WilwoodW4A Radial Mount6617; 17 mm
WilwoodW4A Radial Mount -Quick-Silver6617; 17 mm
WilwoodW4A Radial Mount -Quick-Silver/ST6617; 17 mm
WilwoodW4A Radial Mount-ST6617; 17 mm
WilwoodW6A Radial Mount6617; 17 mm
WilwoodW6A Radial Mount-Quick-Silver6617; 17 mm
WilwoodW6A Radial Mount-Quick-Silver/ST6617; 17 mm
WilwoodW6A Radial Mount-ST6617; 17 mm

Always compare the shape and size with your old pads before you fit them.

Cross references

1 part number from another brand for the same pad shape. Use it to check the fit; it does not mean the pads are the same.

Wilwood
6617

Missing the number from your old pads? Send it to sales@netzschracing.com and we will check it.

Nine formulas, one shape

Every NETZSCH formula is made in the 6617 shape: from the quiet NE11 for the commute to NH70 for GT racing. NC4, NC6 and NC9 are for carbon-ceramic discs.

NE11 brake padsNE11Original Replacement Series, to 500°CN-one brake padsN-oneOriginal Upgrade Series, to 500°CNF42 brake padsNF42High Performance Street Series, to 600°CNG50 brake padsNG50High Performance Street Racing, to 800°CNH65 brake padsNH65High Performance Racetrack Series, to 900°CNH70 brake padsNH70GT Formula Race Edition, to 1200°CNC4 brake padsNC4Carbon Ceramic Entry Series · Data coming soonNC6 brake padsNC6Carbon Ceramic Disc Series, to 600°CNC9 brake padsNC9Carbon Ceramic Race Series · Data coming soonThe lab boy with his flaskCompareSeven tested formulas side by side, and the formula battle
