Fits
EBC
| Model | Chassis | Years | Axle | Details |
|---|---|---|---|---|
| DP4039 | - | - | - | 12.5mm matched by part number |
| DP4039 | - | - | - | 15.5mm matched by part number |
Race calipers
| Brand | Caliper | Notes |
|---|---|---|
| Wilwood | Billet Dynalite - Side Inlet | 7812; 12.4 mm |
| Wilwood | Dynapro Dust-Boot | 7812; 12.4 mm |
| Wilwood | Dynapro Lug Mount | 7812; 12.4 mm |
| Wilwood | Dynapro Lug Mount-ST | 7812; 12.4 mm |
| Wilwood | Dynapro Narrow | 7812; 12.4 mm |
| Wilwood | Forged DPHA | 7812; 12.4 mm |
| Wilwood | Forged XRD Lug Mount | 7812; 12.4 mm |
| Wilwood | Narrow Dynapro Radial Mount | 7812; 12.4 mm |
| Wilwood | UTV4 Caliper | 7812; 12.4 mm |
| Wilwood | UTV6 Caliper | 7812; 12.4 mm |
Always compare the shape and size with your old pads before you fit them. Rows marked “matched by part number” come from other brands' catalogues for a pad of the same shape and size.
Cross references
10 part numbers from other brands for the same pad shape. Use them to check the fit; they do not mean the pads are the same.
- Wilwood
- 7812
- Winmax
- WMP1363 · WMP1363-12.5-W1 · WMP1363-12.5-W3 · WMP1363-12.5-W5 · WMP1363-12.5-W6.5 · WMP1363-15.5-W3 · WMP1363-15.5-W5 · WMP1363-15.5-W6.5 · WMP1363-15.5-W7
Winmax WMP1363: WinmaX catalogue thicknesses 12.5 mm, 15.5 mm
Missing the number from your old pads? Send it to sales@netzschracing.com and we will check it.
