NETZSCH CP3558D46 brake pad drawing: 151.9 × unconfirmed mm, 25 mm thick

CP3558D46

151.9 x 74 x 25 mm

Made to the AP Racing CP3558D46 pad shape. Compare the outline and thickness with your old pads.

Pad shape: AP Racing CP3558D46
Size: 151.9 × 74 mm
Thickness: 25 mm / 18 mm
Use: Race calipers

Formula

NE11Original Replacement Series · to 500°CN-oneOriginal Upgrade Series · to 500°CNF42High Performance Street Series · to 600°CNG50High Performance Street Racing · to 800°CNH65High Performance Racetrack Series · to 900°CNH70GT Formula Race Edition · to 1200°C

For carbon-ceramic discs

NC4Carbon Ceramic Entry SeriesNC6Carbon Ceramic Disc Series · to 600°CNC9Carbon Ceramic Race Series

NH65: High Performance Racetrack Series, rated to 900°C. About NH65

Price on requestRetail prices are being finalised

Request price

Price and stockLoaded from the store for the selected formula; ask us if no price is shown.
DeliveryOptions and cost are shown at checkout for your address.
Before fittingCompare the drawing, size and thickness with the pads you remove.

Shipping · Returns · Warranty

Not sure this is your shape? Use the part finder or ask support.

Fits

Chevrolet

Model	Chassis	Years	Axle	Details
Corvette	-	-	-	C7.R GTE ( Race Car) 14 - matched by part number

Always compare the shape and size with your old pads before you fit them. Rows marked “matched by part number” come from other brands' catalogues for a pad of the same shape and size.

Cross references

6 part numbers from other brands for the same pad shape. Use them to check the fit; they do not mean the pads are the same.

AP Racing: CP3558D46 · CP3894D46
Project Mu: F1094
Winmax: WMP1091 · WMP1091-18-W6.5 · WMP1091-25-W6.5

Winmax WMP1091: 18 mm / 25 mm

Missing the number from your old pads? Send it to sales@netzschracing.com and we will check it.
